Variable Speed – Frequency Controls Available On All Models!

Air Cooled: Chiller, Split System, Self-Contained and Explosion-Proof Systems

60,000 BTU(5 TON) Unit

DSCF2825-1
60,000 BTU(5 TON) unit shown – available in 208/230, 265, 380/420, 440/460, 575 volts – three phase, 50 or 60Hz – This is a roof mounted unit – alternate styles available.

Five Ton Unit Dual Evaporators

DSCF2823-1
This five ton unit has dual evaporators and return plenums and a single supply plenum.

The Condenser End

DSCF2821-1
The condenser end has four condenser coils and a powerful sealed blower motor with a stainless shaft, hub and hardware.

Exclusive Rolled 16 Gauge

DSCF2831-1
Flagship Marines exclusive rolled 16 gauge stainless steel louvers result in greatly reduced air turbulence and greater air flow.
Air Cooled: Self-Contained Specifications and Comparison
Model BTUs of cooling KW of electric heat Specs Length/Width/Height
in inches		 Amps (cool) 230V Wgt lbs. Buy Now
FM24AC
View Image		 24,000 4.0 Manual & Drawing 42/44/28 14 240 INQUIRE
FM36AC
View Image		 36,000 4.0 Manual & Drawing 40/26/24 19 280 INQUIRE
FM48AC
View Image		 48,000 8.0 Manual & Drawing 42/53/28 28 325 INQUIRE
FM60AC
View Image		 60,000 12.0 Manual & Drawing 57/40/28 32 375 INQUIRE
FM96AC 96,000 12.0 78/40/48 32 425 INQUIRE
FM120AC
View Image		 120,000 16.0 Manual & Drawing 112/81/55 32 475 INQUIRE

Flagship Marine Air-Cooled, Weather-Resistant, Roof-Mounted Systems

All components but the condenser blower are in the air-conditioner side of our units to prolong component life.

NO Mildew Drain Pans

Flagship Marine Exclusive: Dry Drain Pan

No more mold and mildew starting in your drain pan! We now manufacture sloped aluminum drain pans that are dry so the condensate water doesn’t have a chance to grow mold and mildew.

When real estate is in short supply, as it always is, how about ten tons (120,000BTUs) of air cooled chilled water on a 22"x 28" footprint!!!!!!

The Outside Panel

DSCF3107-1
The outside panel features a six-row copper/copper condenser with six HP of blowers to accommodate the most extreme conditions!

The Inside Panel

DSCF3109-1

The inside panels are all removable for easy access to everything, and the eye-level, convenient electric box has ALL of the electrical components in it, next to the legendary, over the counter and bulletproof Ranco ETC controller.

NO Mildew Drain Pans

Personalize Your Thermostat!

Our new digital control is programmable or you can override the programs and manually control the temperature.

In addition to a host of features it has a back-lit screen for programming even in the dark.

ANY four wire battery-operated control will operate ANY Flagship Marine Unit

Personalize Your Thermostat

We will laser etch your vessel name here for only $35.00

Choose Flagship Marine for the most rugged, commercial quality air cooled and explosion-proof systems available!

Manufactured with Pride in the USA
